10H-150mA Inductance Choke Coil Transformer – Pure Copper Wire, 66 Silicon Steel Sheets, 22X32 Core

About This Product

This is a 10H-150mA inductance choke coil transformer built with pure copper wire and a solid silicon steel sheet stack.
It's designed for power supply filtering and similar applications – basically, it smooths out current and reduces noise.

The core uses 66 silicon steel sheets with a 22X32 skeleton, and it measures about 68mm long, 67mm wide, and 58mm tall, with mounting holes spaced 82mm apart.

Resistance is around 131 ohms, and it weighs in at 0.
93 kg (just under a kilo).

Solid build, decent specs, and the copper wire means good conductivity and less heat.
If you need a choke for your bile machine or other power projects, this one fits the bill.

10H inductance with 150mA current rating for smooth filtering.
Pure copper wire winding for excellent conductivity and durability.
Core: 66 pieces of silicon steel sheet, skeleton size 22X32.

Dimensions: 68 x 67 x 58 mm; mounting hole distance 82 mm.

DC resistance approx.

131 ohms; net weight 0.

93 kg.
Great for power transformers, bile machines, and other choke applications.
