6-Pack Radial Lead Voltage Dependent Resistor – AC 275V S14K275, 350V DC, 4500A Peak Current, Epoxy Coated For Surge Protection

About This Product

If you're building or repairing power supplies, surge protectors, or any electronics that need protection from voltage spikes, these S14K275 varistors are a must-have.

Each one is a radial lead, epoxy-coated disc that sits across your power rails and goes from high impedance to super low impedance when a spike hits—clamping down that extra voltage before it can fry your sensitive components.

They're rated for AC 275V and DC 350V, with a peak current handling of 4500A, so they can take a serious hit.

Typical capacitance is 320pF, and the body size is about 14mm x 3mm with leads spaced at 7mm.

Standard through-hole footprint, easy to drop into most circuit boards.

You get 6 pieces per pack, which is handy for prototypes, repairs, or stocking your parts drawer.

They're small but they do a big job keeping your gear safe from nasty transients.

Solid choice for hobbyists and pros alike.
