Schneider Electric Multi9 C60SP Miniature Circuit Breaker – 2-Pole, 6A, D Tripping Curve, 10kA, UL1077 & IEC/EN 60947-2

About This Product

This Schneider Electric Multi9 C60SP is a serious piece of protection gear for industrial and commercial setups.

It’s a 2-pole, 6-amp miniature circuit breaker with a D tripping curve – which means it handles those high inrush currents from motors or transformers without nuisance tripping.

Short-circuit breaking capacity is rated at 10kA under both UL1077 and IEC/EN 60947-2 standards, so it’s got you covered worldwide.
Rated voltage goes up to 240V, 415V, or 440V AC depending on the configuration, with insulation rated at 500V AC.
The thermal-magnetic trip unit gives you both overload and short-circuit protection in one neat package.
Mounts on DIN rail – super easy to snap into place.
Ambient operating temp ranges from -30°C to 70°C, so it’s tough enough for harsh environments.

Schneider’s also big on sustainability, aiming for net zero by 2050.
Built for longevity, recyclability, and top-tier performance.

A solid choice for any machine or control panel.
