Square 45mm X 45mm 1/16 DIN Panel Meter Punch Die Set – Fits Greenlee & Metric Punches, 12-Ton Capacity For Steel & Plastic

About This Product

If you're installing meters, gauges, or controllers in electrical panels, this punch die set is exactly what you need.

It's designed to punch a clean 45mm x 45mm square hole—that's the standard 1/16 DIN size—so your meters fit perfectly.
The set includes the punch and die, plus draw studs and spacers that work with both English punch sets (like Greenlee, 3/4-16 thread) and metric punch sets (20 x 1.

5mm thread).
So compatibility is pretty broad.
You'll need a hydraulic punch ram with at least 12 tons of capacity to use this.
It can punch through up to 1/8-inch steel (11 gauge), 1/16-inch stainless steel, as well as brass, copper, aluminum (soft alloys only), fiberglass, and plastic.
The construction is hardened tool steel, so it stays sharp and holds up to repeated use.
There's even a metal case with foam inserts to keep all the parts organized and protected.
A pro-grade tool for panel builders, electricians, and industrial maintenance folks.

No more struggling with hole saws or jigsaws for square holes—this thing does it cleanly and quickly.

This square punch die set creates 45mm x 45mm (1/16 DIN) holes for panel meters and gauges.
Includes draw studs and spacers compatible with English (3/4-16") and metric (20 x 1.

5mm) punch systems.
Requires 12-ton hydraulic ram.
Punches up to 1/8" steel, 1/16" stainless steel, and various other materials.
Hardened tool steel construction.
Comes in a protective metal case.

A must-have for electrical panel work.
